Analogue oscillators typically drift out of tune as time passes. Tuning calibrations are intended to restore the tuning stability of the oscillators, facilitating easier play with accompanying music. Within this article, we are going to learn how to test your synth's tuning, and how to perform a tuning calibration.
Testing The Synth
- Connect the output of the synth to a reliable tuner.
- Hold the PANEL button for one second to load an initialized patch.
- Set OSC 1 TUNE to 12 O'clock.
- Set OSC 2 FREQ to 12 O'clock.
- Set both OSCILLATORS WAVESHAPES to a harmonically rich shape, such as a SAWTOOTH for easier detection.
- Set OSC 2 OCTAVE to higher than OSC 1 OCTAVE for more separation.
- In the MIXER, turn off OSC 2 and turn on OSC 1.
- Play a note on the keyboard.
- Ensure that the tuner is detecting the correct note with a margin of a few cents.
- In the MIXER, turn off OSC 1 and turn on OSC 2.
- Play a note on the keyboard.
- Ensure that the tuner is detecting the correct note with a margin of a few cents.
- In the MIXER, turn on OSC 1 & 2.
- You should be able to adjust OSC 2 accordingly within contrast of OSC 1. OSC 2 operates as a bipolar control, allowing you to either add or subtract 7 semitones depending on the direction you turn the knob.
- CONFIG view by pressing SETTINGS and then PGM button 16 (CONFIG).
- Press PAGE LEFT so that LED 64 is lit - indicating you are on page 4 of the CONFIG options.
- Hold PGM button 14 to run the tuning procedure.
Running The Tuning Procedure
- CONFIG view by pressing SETTINGS and then PGM button 16 (CONFIG).
- Press PAGE LEFT so that LED 64 is lit - indicating you are on page 4 of the CONFIG options.
- Hold PGM button 14 to run the tuning procedure.
